How to install the ABS Control Module on Toyota Solara?

You must tighten the brake actuator assembly with two nuts at 5.4 Nm torque while employing 55 kgf-cm, 48 in-lbf. Follow by attaching the actuator to its bracket through 3 bolts that should be torqued to 19 Nm (194 kgf-cm, 14 ft-lbf) while taking care to avoid hitting brake tubes and wire harness. Using Special Service Tool: 09023-00101 and a torque of 15 Nm (155 kgf-cm, 11 ft-lbf) connect each brake tube to the appropriate positions on the actuator with bracket. Follow brake fluid filling by completing the brake master cylinder sub-assembly bleeder process as well as bleeding the brake line. Users must inspect for brake fluid leakage while checking the reservoir fluid level. To complete the task users must reconnect the battery negative terminal even though some systems need initialization following battery connection. Begin the procedure by initializing the system and proceed to calibrate the yaw rate sensor zero points. The final check should be for the brake actuator using the Techstream system.

How to remove the ABS Control Module for Antilock Brakes on Toyota Solara?

Begin Hydraulic Control Assembly for Antilock Brakes removal by first draining brake fluid before washing away the fluid which touches painted surfaces. After disconnecting the negative terminal of the battery some systems need to initiate processes during reconnection. Special Service Tool 09961-24510 enables the removal process of the brake actuator with bracket by disconnecting its 6 brake tubes with bracket. It is essential to mark the tube locations for proper future reconnection. Start by pulling the lock lever upwards then disconnecting the actuator connector and the subsequent removal of 3 bolts through which the actuator with bracket remains attached while being cautious about brake tubes and wire harness safety. The brake actuator assembly comes off from the brake actuator bracket by removing two nuts.

OEM Toyota Solara ABS Control Module

Anti Lock Brake Control Module

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

9 ABS Control Modules found

View related parts
Toyota Solara Modulator Valve
Part Number: 44050-33190
$1058.38 MSRP: $1332.29
You Save: $273.91 (21%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Filter Assembly, Power Steering; ABS Hydraulic Assembly; ABS Control Module; Actuator; Actuator Assembly, Brake
- Manufacturer Note: VEHICLE STABILITY CONT-WITH
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2007-2008 Toyota Solara | SE, SLE, Sport | 4 Cyl 2.4 L GAS, 6 Cyl 3.3 L GAS
View related parts
Toyota Solara Actuator Assembly, Brake
Part Number: 44050-33110
$793.47 MSRP: $998.82
You Save: $205.35 (21%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: ABS Control Module
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004-2006 Toyota Solara | SE, SE Sport, SLE | 4 Cyl 2.4 L GAS, 6 Cyl 3.3 L GAS
View related parts
Toyota Solara Modulator Valve
Part Number: 44050-06060
$873.48 MSRP: $1099.55
You Save: $226.07 (21%)
ADD TO CART
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Hydraulic Assembly; ABS Modulator Valve; ABS Control Module; Actuator
- Manufacturer Note: W(ABS)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004-2008 Toyota Solara | SE, SE Sport, SLE, Sport | 4 Cyl 2.4 L GAS, 6 Cyl 3.3 L GAS
View related parts
Toyota Solara Control Module
Part Number: 89540-33120
Product Specifications
- Other Name: Computer Assembly, Skid; ABS Control Module; Computer Assembly, Skid Control
- Manufacturer Note: CALIFORNIA SPEC & W(TRACTION CONTROL)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1999 Toyota Solara | SE, SLE | 4 Cyl 2.2 L GAS, 6 Cyl 3.0 L GAS
View related parts
Toyota Solara Control Module
Part Number: 89540-33080
Product Specifications
- Other Name: Computer Assembly, Skid; ABS Control Module; Computer Assembly, Skid Control
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2000-2003 Toyota Solara | SE, SLE | 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L GAS
View related parts
Toyota Solara Control Module
Part Number: 89540-33070
Product Specifications
- Other Name: Computer Assembly, Skid; ABS Control Module; Computer Assembly, Skid Control
- Manufacturer Note: W(TRACTION CONTROL)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2000 Toyota Solara | SE, SLE | 4 Cyl 2.2 L GAS, 6 Cyl 3.0 L GAS
View related parts
Toyota Solara Control Module
Part Number: 89540-33033
Product Specifications
- Other Name: Computer Assembly, Skid; ABS Control Module; Computer Assembly, Skid Control
- Manufacturer Note: W(TRACTION CONTROL)
- Replaces: 89540-33032, 89540-33030
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1999 Toyota Solara | SE, SLE | 4 Cyl 2.2 L GAS, 6 Cyl 3.0 L GAS
View related parts
Toyota Solara Modulator Valve
Part Number: 44050-06041
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Modulator Valve; ABS Control Module; Actuator
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1999-2003 Toyota Solara | SE, SLE | 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L GAS
View related parts
Toyota Solara Modulator Valve
Part Number: 44050-33030
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Modulator Valve; ABS Control Module; Actuator Assembly; Actuator; Actuator Assembly, ABS & Traction
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1999-2003 Toyota Solara | SE, SLE | 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L GAS

Toyota Solara ABS Control Module

Choose genuine ABS Control Module that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM ABS Control Module for your Toyota Solara? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Solara parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

Toyota Solara ABS Control Module Parts and Q&A

Modulator Valve
44050-06060
Q: How to install the ABS Control Module on Toyota Solara?
A:
You must tighten the brake actuator assembly with two nuts at 5.4 Nm torque while employing 55 kgf-cm, 48 in-lbf. Follow by attaching the actuator to its bracket through 3 bolts that should be torqued to 19 Nm (194 kgf-cm, 14 ft-lbf) while taking care to avoid hitting brake tubes and wire harness. Using Special Service Tool: 09023-00101 and a torque of 15 Nm (155 kgf-cm, 11 ft-lbf) connect each brake tube to the appropriate positions on the actuator with bracket. Follow brake fluid filling by completing the Brake Master Cylinder sub-assembly bleeder process as well as bleeding the brake line. Users must inspect for brake fluid leakage while checking the reservoir fluid level. To complete the task users must reconnect the battery negative terminal even though some systems need initialization following battery connection. Begin the procedure by initializing the system and proceed to calibrate the yaw rate sensor zero points. The final check should be for the brake actuator using the Techstream system.
Modulator Valve
44050-33190
Q: How to remove the ABS Control Module for Antilock Brakes on Toyota Solara?
A:
Begin Hydraulic Control Assembly for Antilock Brakes removal by first draining brake fluid before washing away the fluid which touches painted surfaces. After disconnecting the negative terminal of the battery some systems need to initiate processes during reconnection. Special Service Tool 09961-24510 enables the removal process of the brake actuator with bracket by disconnecting its 6 brake tubes with bracket. It is essential to mark the tube locations for proper future reconnection. Start by pulling the lock lever upwards then disconnecting the actuator connector and the subsequent removal of 3 bolts through which the actuator with bracket remains attached while being cautious about brake tubes and wire harness safety. The brake actuator assembly comes off from the brake actuator bracket by removing two nuts.
