How to service and repair the front brake caliper on Toyota Sequoia?

A proper start to front brake caliper repair and service requires first removing the front wheel while torquing it to 110 Nm (1,150 kgf-cm, 83 ft. lbs.). Use Special Service Tool: 09023-00100 to disconnect the brake line while catching all brake fluid in a container using a torque of 15 Nm (155 kgf-cm, 11 ft. lbs.). The caliper removal process begins by detaching the 2 bolts that must be secured at 123 Nm (1,250 kgf-cm, 90 ft. lbs.). From there, extract the clip accompanied by both pins and anti-rattle spring and continue by removing 2 pads and their associated 4 anti-squeal shims. After finishing the installation reverse the removal procedure and then fill the brake reservoir with brake fluid and conduct a brake system bleed while inspecting for any possible leakage.

How to service and repair the rear brake caliper on Toyota Sequoia?

Start servicing and repairing the rear brake caliper by first taking out the cylinder boots through screwdriver usage. Put a cloth piece between the caliper and piston before sucking out the piston from the cylinder using compressed air while avoiding finger contact in front of the piston. Begin service on the rear caliper by using a screwdriver to remove the piston seal before taking out the cap and bleeder plug which must be torqued to 11 Nm (110 kgf-cm, 8 ft. lbs.). Succeed in removing the boot and bushing along with the plug. The pad lining thickness requires ruler measurement for inspections where 10.0 mm (0.39 inch) represents the standard measurement yet the minimum stands at 1.0 mm (0.039 inch). Replace pads if they reach minimum requirements or show signs of uneven wear. A micrometer should verify the disc thickness by temporarily installing the three hub nuts but the standard measurement stands at 18.0 mm (0.709 inch) while the minimum is set at 16.0 mm (0.611 inch). Disc replacement or grinding is required if the thickness falls within these limits or if the components show scoring or uneven wear patterns. A dial indicator should measure disc runout at 10 mm (0.39 inch) from its outside edge to ensure it maintains runout below 0.1 mm (0.0039 inch). Check bearing play and axle hub runout when measuring exceeds this limit. Adjustment of the installation requires disc removal first through backing plate torque plate and bolt removal. The disc must be reinstalled with a 1/6 turn rotation from its prior hub location and subsequent hub nut torque to 110 Nm (1,150 kgf-cm, 83 ft. lbs.). The technician should reinstall the disc starting at different positions on the hub until the minimum runout reaches under 0.1 mm (0.0039 inch). Disc replacement is necessary if the minimum runout measurement exceeds this threshold value. The torque plate should be placed last before bolting the system with 105 Nm (1,070 kgf-cm, 77 ft. lbs.). The reverse procedure of disassembly enables machine reassembly required by the technicians to apply lithium soap base glycol grease on specified parts.

OEM Toyota Sequoia Brake Caliper

Caliper

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

16 Brake Calipers found

View related parts
Toyota Sequoia Caliper, Driver Side
Part Number: 47750-0C030
$203.51 MSRP: $290.57
You Save: $87.06 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Left; Cylinder Assembly, Disc Brake, Driver Side; Brake Caliper
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2015 Toyota Sequoia | Limited, Platinum, SR5 | 8 Cyl 4.6 L GAS, 8 Cyl 4.7 L GAS, 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Caliper, Passenger Side
Part Number: 47730-0C030
$203.51 MSRP: $290.57
You Save: $87.06 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Right; Cylinder Assembly, Front Disc Brake, Passenger Side; Brake Caliper
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2015 Toyota Sequoia | Limited, Platinum, SR5 | 8 Cyl 4.6 L GAS, 8 Cyl 4.7 L GAS, 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Caliper, Driver Side
Part Number: 47750-0C040
$238.58 MSRP: $340.63
You Save: $102.05 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Left; Cylinder Assembly, Disc Brake, Driver Side; Brake Caliper
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2016-2022 Toyota Sequoia | Limited, Nightshade, Platinum, SR5, TRD Pro, TRD Sport | 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Caliper, Driver Side
Part Number: 47750-0C022
$239.16 MSRP: $341.47
You Save: $102.31 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Left; Cylinder Assembly, Disc Brake, Driver Side; Brake Caliper
- Position: Driver Side
- Replaces: 47750-0C021, 47750-0C020, 47750-34040
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2003-2007 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7 L GAS
View related parts
Toyota Sequoia Caliper, Passenger Side
Part Number: 47730-0C040
$238.58 MSRP: $340.63
You Save: $102.05 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Right; Cylinder Assembly, Front Disc Brake, Passenger Side; Brake Caliper
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2016-2022 Toyota Sequoia | Limited, Nightshade, Platinum, SR5, TRD Pro, TRD Sport | 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Caliper, Passenger Side
Part Number: 47730-0C022
$239.16 MSRP: $341.47
You Save: $102.31 (30%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Right; Cylinder Assembly, Front Disc Brake, Passenger Side; Brake Caliper
- Position: Passenger Side
- Replaces: 47730-0C021, 47730-0C020, 47730-34040
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2003-2007 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7 L GAS
View related parts
Toyota Sequoia Caliper, Rear Driver Side
Part Number: 47850-0C010
$121.13 MSRP: $171.48
You Save: $50.35 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly; Disc Brake Caliper, Rear Left; Cylinder Assembly, Disc Brake, Rear Driver Side; Brake Caliper
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2015 Toyota Sequoia | Limited, Platinum, SR5 | 8 Cyl 4.6 L GAS, 8 Cyl 4.7 L GAS, 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Caliper, Passenger Side
Part Number: 47830-0C010
$121.13 MSRP: $171.48
You Save: $50.35 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly; Disc Brake Caliper, Rear Right; Cylinder Assembly, Rear Disc Brake, Passenger Side; Brake Caliper
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2015 Toyota Sequoia | Limited, Platinum, SR5 | 8 Cyl 4.6 L GAS, 8 Cyl 4.7 L GAS, 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Cylinder Assembly, Disc Brake, Rear Driver Side
Part Number: 47750-34030
$172.47 MSRP: $244.15
You Save: $71.68 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Brake Caliper
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2007 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7 L GAS
View related parts
Toyota Sequoia Cylinder Assembly, Rear Disc Brake, Passenger Side
Part Number: 47730-34030
$164.14 MSRP: $232.36
You Save: $68.22 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Brake Caliper
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2007 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7 L GAS
View related parts
Toyota Sequoia Caliper, Rear Driver Side
Part Number: 47850-0C020
$131.59 MSRP: $186.27
You Save: $54.68 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Rear Disc Brake; Disc Brake Caliper, Rear Left; Cylinder Assembly, Disc Brake, Rear Driver Side; Brake Caliper
- Position: Rear Driver Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2016-2022 Toyota Sequoia | Limited, Nightshade, Platinum, SR5, TRD Pro, TRD Sport | 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Caliper, Passenger Side
Part Number: 47830-0C020
$131.59 MSRP: $186.27
You Save: $54.68 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Rear Disc Brake; Disc Brake Caliper, Rear Right; Cylinder Assembly, Rear Disc Brake, Passenger Side; Brake Caliper
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2016-2022 Toyota Sequoia | Limited, Nightshade, Platinum, SR5, TRD Pro, TRD Sport | 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Sequoia Caliper, Driver Side
Part Number: 47750-0C060
$165.43 MSRP: $234.19
You Save: $68.76 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Left; Cylinder Assembly, Disc Brake, Driver Side
- Position: Driver Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023-2024 Toyota Sequoia | Capstone, Limited, Platinum, SR5, TRD Pro | 6 Cyl 3.4 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Sequoia Caliper, Passenger Side
Part Number: 47730-0C060
$188.83 MSRP: $269.62
You Save: $80.79 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Right; Cylinder Assembly, Front Disc Brake, Passenger Side
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023-2024 Toyota Sequoia | Capstone, Limited, Platinum, SR5, TRD Pro | 6 Cyl 3.4 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Sequoia Caliper, Driver Side
Part Number: 47750-0C011
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Left; Cylinder Assembly, Disc Brake, Driver Side; Brake Caliper
- Manufacturer Note: CALIPER=TYPE A:REFER TO ILLUSTRATION
- Position: Driver Side
- Replaces: 47750-0C010
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2003 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7 L GAS
View related parts
Toyota Sequoia Caliper, Passenger Side
Part Number: 47730-0C011
Product Specifications
- Other Name: Cylinder Assembly, Disc; Disc Brake Caliper, Front Right; Cylinder Assembly, Front Disc Brake, Passenger Side; Brake Caliper
- Manufacturer Note: CALIPER=TYPE A:REFER TO ILLUSTRATION
- Position: Passenger Side
- Replaces: 47730-0C010
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2003 Toyota Sequoia | Limited, SR5 | 8 Cyl 4.7 L GAS

Toyota Sequoia Brake Caliper

Choose genuine Brake Caliper that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM Brake Caliper for your Toyota Sequoia? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Sequoia parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

The Brake Caliper of Toyota Sequoia vehicles forms part of the braking system and has the task of clamping the brake pads over the rotors to produce friction hence stop the car. These calipers come in two main types: The two major types are the fixed and floating types. The fixed calipers reside in the brake and have two pistons on the opposite side of the disc, giving more consistent performance but with significantly less tolerance for flaws in the disc's surface. The other kind of calipers are floating calipers for which a single piston has to operate the inner brake pad and as a result have to slide the caliper and apply pressure on both sides of the disc. However, floating calipers can be affected by sticking factors that contribute to poor fuel economy, disc overheating and inconsistent wear pattern on the pads. In the case of Toyota Sequoia vehicles, the Brake Caliper is the component that actually converts the hydraulic pressure into mechanical force to decelerate or to bring the vehicle to a complete stop especially when using disc brakes. In particular, these calipers are usually of cast iron construction with steel or phenolic for the pistons. The replacement calipers run the whole gamut from simple precision manufactured ones, through semi loaded ones that also come with hardware and brackets, to loaded ones complete with new pistons seals, boots, hardware of course and even application specific brake pads, if the complete overhaul of the brake caliper is in order. If the user's performance improvement priorities include sharp stopping ability, a wide range of performance calipers is available inclusive of low-priced cast calipers to the optimal billet aluminum for racing cars.

Toyota Sequoia Brake Caliper Parts and Q&A

Caliper, Driver Side
47750-0C011
Q: How to service and repair the front brake caliper on Toyota Sequoia?
A:
A proper start to front brake caliper repair and service requires first removing the front wheel while torquing it to 110 Nm (1,150 kgf-cm, 83 ft. lbs.). Use Special Service Tool: 09023-00100 to disconnect the Brake Line while catching all brake fluid in a container using a torque of 15 Nm (155 kgf-cm, 11 ft. lbs.). The caliper removal process begins by detaching the 2 bolts that must be secured at 123 Nm (1,250 kgf-cm, 90 ft. lbs.). From there, extract the clip accompanied by both pins and anti-rattle spring and continue by removing 2 pads and their associated 4 anti-squeal shims. After finishing the installation reverse the removal procedure and then fill the brake reservoir with brake fluid and conduct a brake system bleed while inspecting for any possible leakage.
Cylinder Assembly, Disc Brake, Rear Driver Side
47750-34030
Q: How to service and repair the rear brake caliper on Toyota Sequoia?
A:
Start servicing and repairing the rear brake caliper by first taking out the cylinder boots through screwdriver usage. Put a cloth piece between the caliper and piston before sucking out the piston from the cylinder using compressed air while avoiding finger contact in front of the piston. Begin service on the rear caliper by using a screwdriver to remove the piston seal before taking out the cap and bleeder plug which must be torqued to 11 Nm (110 kgf-cm, 8 ft. lbs.). Succeed in removing the boot and bushing along with the plug. The pad lining thickness requires ruler measurement for inspections where 10.0 mm (0.39 inch) represents the standard measurement yet the minimum stands at 1.0 mm (0.039 inch). Replace pads if they reach minimum requirements or show signs of uneven wear. A micrometer should verify the disc thickness by temporarily installing the three hub nuts but the standard measurement stands at 18.0 mm (0.709 inch) while the minimum is set at 16.0 mm (0.611 inch). Disc replacement or grinding is required if the thickness falls within these limits or if the components show scoring or uneven wear patterns. A dial indicator should measure disc runout at 10 mm (0.39 inch) from its outside edge to ensure it maintains runout below 0.1 mm (0.0039 inch). Check bearing play and axle hub runout when measuring exceeds this limit. Adjustment of the installation requires disc removal first through backing plate torque plate and bolt removal. The disc must be reinstalled with a 1/6 turn rotation from its prior hub location and subsequent hub nut torque to 110 Nm (1,150 kgf-cm, 83 ft. lbs.). The technician should reinstall the disc starting at different positions on the hub until the minimum runout reaches under 0.1 mm (0.0039 inch). Disc replacement is necessary if the minimum runout measurement exceeds this threshold value. The torque plate should be placed last before bolting the system with 105 Nm (1,070 kgf-cm, 77 ft. lbs.). The reverse procedure of disassembly enables machine reassembly required by the technicians to apply lithium soap base glycol grease on specified parts.
