How to install the ABS Control Module on Toyota Venza?

Two nuts should be attached to join the brake actuator assembly with the brake actuator bracket assembly and achieve a torque rating of 8.0 Nm (82 kgf-cm, 71 in-lbf). New brake actuators should never have their hole plugs removed before 6 brake line connection since they contain brake fluid and should be placed on the ground with the pin installed rather than being handled by the connector. The brake actuator requires installation with its bracket to the body using a nut together with 2 bolts according to a torque standard of 19 Nm (194 kgf-cm, 14 ft-lbf). The installer should check for brake line and wire harness damage in addition to following the tightening sequence from 1 to 3. Securely attach the brake actuator connector until it locks while checking for any entry of water and oil and dirt. Before final tightening use union nut wrenches to fasten the brake lines on the brake actuator bracket with the specified torque of 15 Nm (155 kgf-cm, 11 ft-lbf) for Flare nut A (10 mm) and 20 Nm (199 kgf-cm, 14 ft-lbf) for Flare Nut B (12 mm). The clamp from the suction hose sub-assembly should be installed onto the brake actuator bracket assembly. Install the complete radiator reserve tank assembly together with its appropriate cap. Start by filling brake fluid into the reservoir after which you must bleed the brake master cylinder followed by bleeding the brake line. Check both the fluid level inside the reservoir and look for evidence of brake fluid leakage on the car. Attach the cable to the negative battery terminal but initialization procedures might be required for certain systems after the connection. Run an engine variant learning process while using Techstream to inspect the brake actuator.

OEM Toyota Venza ABS Control Module

Anti Lock Brake Control Module

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

6 ABS Control Modules found

View related parts
Toyota Venza Modulator Valve
Part Number: 44050-48C22
$951.12 MSRP: $1197.28
You Save: $246.16 (21%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Actuator Assembly, Brake; Actuator Assembly
- Manufacturer Note: *614
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023 Toyota Venza | LE, Limited, XLE | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Venza Modulator Valve
Part Number: 44050-48C21
$1043.62 MSRP: $1313.71
You Save: $270.09 (21%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Hydraulic Assembly; Actuator Assembly
- Manufacturer Note: *614
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022 Toyota Venza | LE, Limited, XLE | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Venza Modulator Valve
Part Number: 44050-48C20
$1045.89 MSRP: $1316.58
You Save: $270.69 (21%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Hydraulic Assembly; ABS Pump And Motor Assembly; ABS Control Module; Actuator Assembly
- Manufacturer Note: *614
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2021-2022 Toyota Venza | LE, Limited, XLE | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Venza Modulator Valve
Part Number: 44050-0T030
$950.32 MSRP: $1196.27
You Save: $245.95 (21%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Hydraulic Assembly; ABS Control Module; Actuator
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2013-2015 Toyota Venza | LE, Limited, XLE | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS
View related parts
Toyota Venza Modulator Valve
Part Number: 44050-0T021
$1019.33 MSRP: $1283.14
You Save: $263.81 (21%)
ADD TO CART
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Hydraulic Assembly; ABS Control Module; Actuator
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2011-2012 Toyota Venza | Base, LE, Limited, XLE | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS
View related parts
Toyota Venza Modulator Valve
Part Number: 44050-0T012
$1081.87 MSRP: $1361.86
You Save: $279.99 (21%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Actuator Assembly, Brake; ABS Hydraulic Assembly; ABS Control Module; Actuator
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2009-2010 Toyota Venza | Base | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS

Toyota Venza ABS Control Module

Choose genuine ABS Control Module that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM ABS Control Module for your Toyota Venza? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Venza parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

The Toyota Venza abs control module as of the anti-lock braking module is an important cpu well-known to be reliable and efficient in different venza models. This module has a significant responsibility also in as far as safety of the vehicles and the passengers is concerned since wheel lock-up and loss of control can occur during hard braking which is relieved by this very module. The Toyota Venza is a mid-size crossover SUV vehicle that has been recognized for its safety features and the Top Safety Pick award the Insurance Institute for Highway Safety IIHS for several years. The ABS Control Module works hand in hand with wheel speed sensors, valves, a pump, and the electronic control unit to control the braking force required in real-time thereby increasing efficiency and safety. Subtypes of the ABS Control Module in Toyota Venza may also include the ESC and the traction control; the former is an adjunct for handling paved your skids between the wheels through selective braking. Thus, using this integration of technology does not only improve performance but also adds to the reliability of Toyota Venza. ABS Control Module has the ability to work with different kinds of Venza models, which is regarded as a crucial factor in the automotive industry due to the richness of features and commitment to safety. In general, the Toyota Venza ABS Control Module reflects the company's commitment to providing Customers with qualitative and long-lasting parts, which improve the driving experience and increase the level of RAMS for all the Owners of Venza automobiles.

Toyota Venza ABS Control Module Parts and Q&A

Modulator Valve
44050-0T012
Q: How to install the ABS Control Module on Toyota Venza?
A:
Two nuts should be attached to join the brake actuator assembly with the brake actuator bracket assembly and achieve a torque rating of 8.0 Nm (82 kgf-cm, 71 in-lbf). New brake actuators should never have their hole plugs removed before 6 Brake Line connection since they contain brake fluid and should be placed on the ground with the pin installed rather than being handled by the connector. The brake actuator requires installation with its bracket to the body using a nut together with 2 bolts according to a torque standard of 19 Nm (194 kgf-cm, 14 ft-lbf). The installer should check for brake line and wire harness damage in addition to following the tightening sequence from 1 to 3. Securely attach the brake actuator connector until it locks while checking for any entry of water and oil and dirt. Before final tightening use union nut wrenches to fasten the brake lines on the brake actuator bracket with the specified torque of 15 Nm (155 kgf-cm, 11 ft-lbf) for Flare nut A (10 mm) and 20 Nm (199 kgf-cm, 14 ft-lbf) for Flare Nut B (12 mm). The clamp from the suction hose sub-assembly should be installed onto the brake actuator bracket assembly. Install the complete radiator reserve tank assembly together with its appropriate cap. Start by filling brake fluid into the reservoir after which you must bleed the Brake Master Cylinder followed by bleeding the brake line. Check both the fluid level inside the reservoir and look for evidence of brake fluid leakage on the car. Attach the cable to the negative battery terminal but initialization procedures might be required for certain systems after the connection. Run an engine variant learning process while using Techstream to inspect the brake actuator.
