How to remove and install the Curtain Shield Air Bag Sensor Assembly on 2005 Toyota Tundra?

Safety procedures for removing and installing the Curtain Shield Air Bag Sensor Assembly start with disconnecting the negative battery terminal followed by a 90-second rest time to avoid Air Bag activation. The process begins by removing the rear door scuff plate followed by the back panel trim assembly and then the rear seat outer belt floor anchor. After that, quarter trim panel lower LH and rear seat outer belt retractor need to be removed. Terminate the LH connector from the curtain shield Air Bag sensor assembly then remove its two retaining nuts. A new curtain shield Air Bag sensor assembly must be used when replacing a sensor which activated during an accident or displays any visible wear. Use new sensor assembly LH by installing it with two nuts at 17.5 N.m (179 kgf.cm, and 13 ft.lbf) torque before reattaching the LH connector. The installation procedures include positioning the rear seat outer belt retractor followed by quarter trim panel lower LH and rear seat outer belt floor anchor and back panel trim assembly and rear door scuff plate. After completing the task disconnect the negative terminal of the battery before checking for SRS warning light function and safety.

OEM 2005 Toyota Tundra Air Bag Sensor

Air Bag Impact Sensor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Air Bag Sensors found

View related parts
2005 Toyota Tundra Diagnostic Module
Part Number: 89170-0C221
$227.19 MSRP: $278.62
You Save: $51.43 (19%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly, Air Bag
- Replaces: 89170-0C220
- Item Weight: 1.60 Pounds
- Item Dimensions: 7.6 x 6.6 x 3.9 inches
- Condition: New
- SKU: 89170-0C221
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Side Impact Sensor, Passenger Side
Part Number: 89860-0C050
$227.08 MSRP: $278.48
You Save: $51.40 (19%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly, Side Air Bag; Air Bag Impact Sensor, Front Left; Air Bag Sensor; Side Sensor; Sensor Assembly, Side Air Bag, Passenger Side
- Position: Passenger Side
- Part Name Code: 89860
- Item Weight: 0.60 Pounds
- Item Dimensions: 4.3 x 2.6 x 2.1 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89860-0C050
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Air Bag Sensor, Front Driver Side
Part Number: 89174-09040
$98.46 MSRP: $118.71
You Save: $20.25 (18%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Bag, Front; Air Bag Impact Sensor, Front Left, Left; Impact Sensor; Front Sensor; Sensor, Air Bag, Front Driver Side
- Position: Front Driver Side
- Part Name Code: 89174A
- Item Weight: 0.70 Pounds
- Item Dimensions: 4.7 x 2.9 x 2.3 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89174-09040
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Impact Sensor, Front Driver Side
Part Number: 89174-09021
$98.34 MSRP: $118.58
You Save: $20.24 (18%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Bag, Front; Air Bag Impact Sensor, Left; Air Bag Sensor; Front Sensor; Sensor, Air Bag, Front Driver Side
- Position: Front Driver Side
- Part Name Code: 89174A
- Item Weight: 0.70 Pounds
- Item Dimensions: 4.6 x 3.0 x 2.3 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89174-09021
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Air Bag Sensor, Front Passenger Side
Part Number: 89173-09200
$98.46 MSRP: $118.71
You Save: $20.25 (18%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Bag, Front; Air Bag Impact Sensor, Front Right, Right; Impact Sensor; Front Sensor; Sensor, Air Bag, Front Passenger Side
- Position: Front Passenger Side
- Part Name Code: 89173A
- Item Weight: 0.70 Pounds
- Item Dimensions: 4.7 x 2.9 x 2.3 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89173-09200
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Impact Sensor, Front Passenger Side
Part Number: 89173-09181
$98.34 MSRP: $118.58
You Save: $20.24 (18%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Bag, Front; Air Bag Impact Sensor, Right; Air Bag Sensor; Front Sensor; Sensor, Air Bag, Front Passenger Side
- Position: Front Passenger Side
- Part Name Code: 89173A
- Item Weight: 0.70 Pounds
- Item Dimensions: 4.5 x 2.9 x 2.2 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89173-09181
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Position Sensor, Driver Side
Part Number: 89178-33031
$101.61 MSRP: $142.63
You Save: $41.02 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Seat Position; Air Bag Seat Sensor Mat, Front Left; Seat Track Position Sensor, Left; Air Bag Sensor; Occupant Sensor; Discriminating Sensor; Sensor, Seat Position Air Bag
- Position: Driver Side
- Replaces: 89178-33030
- Part Name Code: 89178A
- Item Weight: 0.50 Pounds
- Item Dimensions: 2.1 x 1.6 x 1.3 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89178-33031
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Limited | 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Position Sensor, Front Driver Side
Part Number: 89178-33020
$99.11 MSRP: $139.12
You Save: $40.01 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Seat Position; Seat Track Position Sensor, Front Left; Air Bag Seat Sensor Mat, Front Left; Air Bag Sensor; Occupant Sensor; Discriminating Sensor; Sensor, Seat Position Air Bag
- Position: Front Driver Side
- Part Name Code: 89178A
- Item Weight: 0.50 Pounds
- Item Dimensions: 2.2 x 1.6 x 1.3 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89178-33020
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Side Impact Sensor, Rear Driver Side
Part Number: 89834-0C030
$285.02 MSRP: $406.94
You Save: $121.92 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Bag, Rear; Air Bag Impact Sensor, Rear Left; Air Bag Sensor; Side Sensor; Sensor, Air Bag, Rear Driver Side
- Position: Rear Driver Side
- Part Name Code: 89834
- Item Weight: 0.60 Pounds
- Item Dimensions: 4.3 x 2.6 x 2.0 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89834-0C030
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
2005 Toyota Tundra Side Impact Sensor, Rear Passenger Side
Part Number: 89833-0C030
$285.02 MSRP: $406.94
You Save: $121.92 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Bag, Rear; Air Bag Impact Sensor, Rear Right; Air Bag Sensor; Side Sensor; Sensor, Air Bag, Rear Passenger Side
- Position: Rear Passenger Side
- Part Name Code: 89833
- Item Weight: 0.60 Pounds
- Item Dimensions: 4.2 x 2.6 x 2.0 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 89833-0C030
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Tundra Submodels:
- Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS

2005 Toyota Tundra Air Bag Sensor

Looking for affordable OEM 2005 Toyota Tundra Air Bag Sensor? Explore our comprehensive catalogue of genuine 2005 Toyota Tundra Air Bag Sensor. All our parts are covered by the manufacturer's warranty. Plus, our straightforward return policy and speedy delivery service ensure an unparalleled shopping experience. We look forward to your visit!

2005 Toyota Tundra Parts Questions & Experts Answers

Q: How to remove and install the Curtain Shield Air Bag Sensor Assembly on 2005 Toyota Tundra?
A: Safety procedures for removing and installing the Curtain Shield Air Bag Sensor Assembly start with disconnecting the negative battery terminal followed by a 90-second rest time to avoid Air Bag activation. The process begins by removing the rear door scuff plate followed by the back panel trim assembly and then the rear seat outer belt floor anchor. After that, quarter trim panel lower LH and rear seat outer belt retractor need to be removed. Terminate the LH connector from the curtain shield Air Bag sensor assembly then remove its two retaining nuts. A new curtain shield Air Bag sensor assembly must be used when replacing a sensor which activated during an accident or displays any visible wear. Use new sensor assembly LH by installing it with two nuts at 17.5 N.m (179 kgf.cm, and 13 ft.lbf) torque before reattaching the LH connector. The installation procedures include positioning the rear seat outer belt retractor followed by quarter trim panel lower LH and rear seat outer belt floor anchor and back panel trim assembly and rear door scuff plate. After completing the task disconnect the negative terminal of the battery before checking for SRS warning light function and safety.
