How to Service and Repair a Shock Absorber on 2005 Toyota Celica?

Service the suspension strut by first taking off the front wheel after tightening it to 103 Nm torque (1,050 kgf-cm, 76 ft. lbs.). First disconnect the ABS speed sensor wire harness clamps from the shock absorber by removing the bolt while tightening it to 8.0 Nm (82 kgf-cm, 71 inch lbs.). Next disconnect the flexible hose from the shock absorber bracket by loosening the bolt which should be mounted at 19 Nm (192 kgf-cm, 14 ft. lbs.). The stabilizer bar link gets disconnected from the shock absorber through nut removal followed by torque application at 44 Nm (449 kgf-cm, 32 ft. lbs.) but if the ball joint turns with the nut implementation a hexagon (5 mm) wrench should hold the stud. The first step for the shock absorber with coil spring is to lower the torque on its 2 lower side nuts to 153 Nm (1,560 kgf-cm, 113 ft. lbs.) while leaving the bolts in place. The shock absorber maintenance process involves first untightening three upper side nuts with 39 Nm torque (400 kgf-cm, 29 ft. lbs.) then removing the lower side nuts and bolts while applying engine oil to the threads before installing. The removal sequence ends with taking out the shock absorber with coil spring. The installation procedure should be performed the exact reverse of removal and verify front wheel alignment after the system installation is complete.

OEM 2005 Toyota Celica Shock Absorber

Suspension Shock Absorber

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

4 Shock Absorbers found

View related parts
2005 Toyota Celica Strut, Front Passenger Side
Part Number: 48510-80324
$119.13 MSRP: $168.65
You Save: $49.52 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Assembly, Shock; Suspension Strut, Front Right; Shock Absorber
- Position: Front Passenger Side
- Replaces: 48510-80072, 48510-80220, 48510-80221, 48510-80071, 48510-29755, 48510-29756, 48510-80325
- Item Weight: 1.40 Pounds
- Item Dimensions: 26.4 x 8.4 x 7.6 inches
- Condition: New
- SKU: 48510-80324
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Celica Submodels:
- GT, GTS | 4 Cyl 1.8 L GAS
View related parts
2005 Toyota Celica Shock Absorber, Rear Passenger Side
Part Number: 48530-80331
$88.27 MSRP: $123.91
You Save: $35.64 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Set, Rear Right-Hand; Shock Absorber, Rear; Suspension Strut Assembly Kit; Complete Strut Kit; Complete Strut; Strut; Absorber Assembly, Shock, Rear Passenger Side; Absorber Assembly, Shock, Rear Driver Side
- Manufacturer Note: MARK 48530-2B830
- Position: Rear Passenger Side
- Replaces: 48530-29775
- Item Weight: 4.70 Pounds
- Item Dimensions: 26.1 x 6.7 x 5.9 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 48530-80331
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Celica Submodels:
- GT, GTS | 4 Cyl 1.8 L GAS
View related parts
2005 Toyota Celica Strut, Front Driver Side
Part Number: 48520-80101
$119.13 MSRP: $168.65
You Save: $49.52 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Assembly, Shock; Suspension Strut, Front Left; Shock Absorber
- Position: Front Driver Side
- Replaces: 48520-29675, 48520-80046, 48520-80102, 48520-29465, 48520-29466, 48520-29665, 48520-80047
- Item Weight: 1.40 Pounds
- Item Dimensions: 27.1 x 8.5 x 7.6 inches
- Condition: New
- SKU: 48520-80101
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Celica Submodels:
- GT, GTS | 4 Cyl 1.8 L GAS
View related parts
2005 Toyota Celica Shock Absorber
Part Number: 48530-80079
$101.90 MSRP: $143.03
You Save: $41.13 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Assembly, Shock; Shock Absorber, Rear; Suspension Strut Assembly Kit; Complete Strut Kit; Complete Strut; Strut; Absorber Assembly, Shock, Rear Passenger Side; Absorber Assembly, Shock, Rear Driver Side
- Manufacturer Note: MARK 48530-2B830
- Item Weight: 7.10 Pounds
- Item Dimensions: 26.1 x 6.8 x 5.7 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 48530-80079
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
More Info
Fits the following 2005 Toyota Celica Submodels:
- GT, GTS | 4 Cyl 1.8 L GAS

2005 Toyota Celica Shock Absorber

Looking for affordable OEM 2005 Toyota Celica Shock Absorber? Explore our comprehensive catalogue of genuine 2005 Toyota Celica Shock Absorber. All our parts are covered by the manufacturer's warranty. Plus, our straightforward return policy and speedy delivery service ensure an unparalleled shopping experience. We look forward to your visit!

2005 Toyota Celica Parts Questions & Experts Answers

Q: How to Service and Repair a Shock Absorber on 2005 Toyota Celica?
A: Service the suspension strut by first taking off the front wheel after tightening it to 103 Nm torque (1,050 kgf-cm, 76 ft. lbs.). First disconnect the ABS speed sensor wire harness clamps from the shock absorber by removing the bolt while tightening it to 8.0 Nm (82 kgf-cm, 71 inch lbs.). Next disconnect the flexible hose from the shock absorber bracket by loosening the bolt which should be mounted at 19 Nm (192 kgf-cm, 14 ft. lbs.). The stabilizer bar link gets disconnected from the shock absorber through nut removal followed by torque application at 44 Nm (449 kgf-cm, 32 ft. lbs.) but if the ball joint turns with the nut implementation a hexagon (5 mm) wrench should hold the stud. The first step for the shock absorber with coil spring is to lower the torque on its 2 lower side nuts to 153 Nm (1,560 kgf-cm, 113 ft. lbs.) while leaving the bolts in place. The shock absorber maintenance process involves first untightening three upper side nuts with 39 Nm torque (400 kgf-cm, 29 ft. lbs.) then removing the lower side nuts and bolts while applying engine oil to the threads before installing. The removal sequence ends with taking out the shock absorber with coil spring. The installation procedure should be performed the exact reverse of removal and verify front wheel alignment after the system installation is complete.
