How to replace the Brake Pad Set on Toyota Prius?

The first step is to check pad lining thickness by looking through the caliper inspection hole while the front wheel is off. Brake pad replacement becomes necessary when pad thickness reaches less than 1.0 mm (0.039 inch). Raise the caliper while holding the sliding pin in place and delete the bottom bolt before making sure the flexible hose stays attached to the brake caliper then secure the caliper in position. Disassembly begins with pad and anti-squeal shim removal together. After that take out the two pad support plates. Retention of the support plates becomes possible if they demonstrate no signs of wear, rust or cracks and no foreign materials are observed. The two pad support platesInstallation should only occur when disc thickness and runout are verified and assembled correctly without reversing the plates For new pad installation, users should change the anti-squeal shims while executing the following procedure: follow each pad with two anti-squeal shims on each side and position the inner pad with the upward wear indicator plate followed by outer pad installation while carefully avoiding contact between oil or grease and friction surfaces. To push in the caliper piston draw small brake fluid from the reservoir then use a hammer handle with tape on the end or similar tool; if the piston is resistant to push in then loosen the bleeder valve to spill some fluid. Secure the sliding pin and torque the installation bolts to 34 Nm while performing this operation. After installing the front wheel complete its torque procedure at 103 Nm (1,050 kgf-cm, 76 ft. lbs.). Then activate the brake pedal multiple times before verifying that the fluid reaches the maximum line.

OEM Toyota Prius Brake Pad Set

Disc Brake Pad Set

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

11 Brake Pad Sets found

View related parts
Toyota Prius Pad Kit, Disc Brake, Rear
Part Number: 04466-76012
$51.98 MSRP: $72.00
You Save: $20.02 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set; Brake Pads
- Manufacturer Note: MARK AK NS254
- Position: Rear
- Replaces: 04466-47020, 04466-52150, 04466-47030, 04466-52151, 04466-76011, 04466-76010, 04466-21020
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2010-2011 Toyota Prius | Base | 4 Cyl 1.8 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Rear
Part Number: 04466-47101
$56.51 MSRP: $78.27
You Save: $21.76 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Rear; Brake Pad Set, Disc Brake; Disc Brake Pad Set; Rear Pads
- Position: Rear
- Replaces: 04466-47100
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2014-2018 Toyota Prius | Five, Four, Four Touring, One, Persona Series, Three, Three Touring, Two, Two Eco | 4 Cyl 1.8 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads
Part Number: 04466-47080
$51.98 MSRP: $72.00
You Save: $20.02 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Rear; Rear Pads
- Replaces: 04466-47061, 04466-47040, 04466-47060
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2011-2013 Toyota Prius | Base, Five, Four, Three, Two | 4 Cyl 1.8 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Front
Part Number: 04465-17140
$76.07 MSRP: $105.63
You Save: $29.56 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Front; Brake Pad Set, Disc Brake; Disc Brake Pad Kit; Front Pads; Pads; Pad Kit, Disc Brake, Front; Disc Brake Pad Set
- Manufacturer Note: MARK NBK PN540H
- Position: Front
- Replaces: 04465-17100, 04465-17101, 04465-52010, 04465-52060
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2003 Toyota Prius | Base | 4 Cyl 1.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Rear
Part Number: 04466-47110
$52.57 MSRP: $72.80
You Save: $20.23 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Rear; Rear Pads; Pad Kit, Disc Brake, Rear; Disc Brake Pad Set
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2019-2022 Toyota Prius | 2020 Edition, L Eco, LE, Limited, XLE | 4 Cyl 1.8 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Front
Part Number: 04465-47080
$75.25 MSRP: $104.50
You Save: $29.25 (28%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Front; Disc Brake Pad Kit; Front Pads; Pad Kit, Disc Brake, Front; Disc Brake Pad Set
- Manufacturer Note: MARK AK NS369H
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2016-2022 Toyota Prius | 2020 Edition, Four, Four Touring, L Eco, LE, Limited, One, Three, Three Touring, Two, Two Eco, XLE | 4 Cyl 1.8 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Pad Kit, Disc Brake, Front
Part Number: 04465-47070
$75.25 MSRP: $104.50
You Save: $29.25 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set; Brake Pads
- Manufacturer Note: MARK ADVICS PV565H
- Position: Front
- Replaces: 04465-47060
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2010-2015 Toyota Prius | Base, Five, Four, One, Persona Series, Three, Two | 4 Cyl 1.8 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Front
Part Number: 04465-47050
$75.25 MSRP: $104.50
You Save: $29.25 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Front; Disc Brake Pad Kit; Front Pads; Pad Kit, Disc Brake, Front; Disc Brake Pad Set
- Manufacturer Note: MARK SUMITOMO PS558H
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004-2009 Toyota Prius | Base, Touring | 4 Cyl 1.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Front
Part Number: 04465-12670
$75.25 MSRP: $104.50
You Save: $29.25 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Front; Disc Brake Pad Kit; Front Pads; Pad Kit, Disc Brake, Front; Disc Brake Pad Set
- Manufacturer Note: MARK ADVICS VC084H
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023 Toyota Prius | LE, Limited, XLE | 4 Cyl 2.0 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Rear
Part Number: 04466-42080
$57.23 MSRP: $79.27
You Save: $22.04 (28%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Disc Brake Pad Set, Rear; Disc Brake Pad Kit; Rear Pads; Pad Kit, Disc Brake, Rear; Disc Brake Pad Set
- Manufacturer Note: MARK NBK 478-XA5
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023 Toyota Prius | LE, Limited, XLE | 4 Cyl 2.0 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Prius Brake Pads, Front
Part Number: 04465-16130
$76.41 MSRP: $107.26
You Save: $30.85 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pad Kit, Disc Brake; Front Pads; Pad Kit, Disc Brake, Front
- Manufacturer Note: MARK ADVICS VC115
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023 Toyota Prius | LE, Limited, XLE | 4 Cyl 2.0 L FULL HYBRID EV-GAS (FHEV)

Toyota Prius Brake Pad Set

If you're thinking about purchasing OEM parts for your Toyota Prius, our website is your one-stop destination. We stock an extensive selection of genuine Toyota Prius Brake Pad Set at pocket-friendly prices. Plus, we guarantee a swift delivery and a hassle-free return policy for your convenience.

Toyota Prius Brake Pad Set Parts Questions & Experts Answers

Brake Pads, Front
04465-17140
Q: How to replace the Brake Pad Set on Toyota Prius?
A: The first step is to check pad lining thickness by looking through the caliper inspection hole while the front wheel is off. Brake pad replacement becomes necessary when pad thickness reaches less than 1.0 mm (0.039 inch). Raise the caliper while holding the sliding pin in place and delete the bottom bolt before making sure the flexible hose stays attached to the brake caliper then secure the caliper in position. Disassembly begins with pad and anti-squeal shim removal together. After that take out the two pad support plates. Retention of the support plates becomes possible if they demonstrate no signs of wear, rust or cracks and no foreign materials are observed. The two pad support platesInstallation should only occur when disc thickness and runout are verified and assembled correctly without reversing the plates For new pad installation, users should change the anti-squeal shims while executing the following procedure: follow each pad with two anti-squeal shims on each side and position the inner pad with the upward wear indicator plate followed by outer pad installation while carefully avoiding contact between oil or grease and friction surfaces. To push in the caliper piston draw small brake fluid from the reservoir then use a hammer handle with tape on the end or similar tool; if the piston is resistant to push in then loosen the bleeder valve to spill some fluid. Secure the sliding pin and torque the installation bolts to 34 Nm while performing this operation. After installing the front wheel complete its torque procedure at 103 Nm (1,050 kgf-cm, 76 ft. lbs.). Then activate the brake pedal multiple times before verifying that the fluid reaches the maximum line.
