How to remove the Trunk Lid Latch assembly on Toyota Highlander?

The first step to remove the back door lock assembly requires the removal of the back window upper panel trim assembly. The left-hand side back door trim cover must be removed from non-power door vehicles whereas those with power doors need both the left-side back door service hole cover removed along with power back door rod disconnection. Vehicles that use a power back door need users to eliminate the left-hand side back door trim cover and the right-hand side back door trim cover in succession. The procedure begins by removing the back door lock cover if the hatch is glass until the assist strap hole cover and assist strap assembly can be unplugged. Next in the order move the back door trim panel assembly. Remove the three bolts and separate the back door lock assembly when working on vehicles without power back doors functionality. The assembly removal process for power back door vehicles requires connector detaching and clamp release as well as four bolt removal from the back door lock assembly.

How to install the Trunk Lid Latch assembly with and without a Power Back Door on Toyota Highlander?

The back door lock assembly installation requires you to fasten 3 bolts at 13 Nm (133 kgf-cm, 10 ft-lbf) torque value and connect all connectors. The installation of the assembly with Power Back Door requires four same-torque bolts while connecting the connector before clamping it into place. The third step involves adding the back door trim panel assembly along with assist strap assembly and assist strap hole cover. The Glass Hatch Type requires a back door lock cover to be installed before both configurations (with and without Power Back Door) receive their left side back door trim cover. The service hole cover of the left Power Back Door needs the back door power rod connection followed by installation. The right side back door trim cover and the back window upper panel trim assembly should be installed as a final step.

OEM Toyota Highlander Trunk Lid Latch

Luggage Compartment Door Lock Assembly

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

8 Trunk Lid Latches found

View related parts
Toyota Highlander Gate Lock, Rear
Part Number: 69350-28151
$179.51 MSRP: $256.30
You Save: $76.79 (30%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch; Tailgate Lock Actuator; Trunk Lock Actuator; Door Lock Actuator; Lock Actuator; Lock Assembly; Lock; Lock Assembly, Back Door, W/Courtesy Lamp Switch
- Manufacturer Note: KOREA SPEC
- Position: Rear
- Replaces: 69350-28150
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2013 Toyota Highlander | Base, Hybrid, Hybrid Limited, Limited, SE, Sport | 4 Cyl 2.7 L GAS, 6 Cyl 3.3 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Gate Lock, Rear
Part Number: 69350-0T020
$346.23 MSRP: $494.33
You Save: $148.10 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch, Rear; Door Lock; Lock Assembly, Back Door, W/Courtesy Lamp Switch
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2014-2019 Toyota Highlander | Hybrid LE, Hybrid Limited, Hybrid Limited Platinum, Hybrid XLE, LE, LE Plus, Limited, Limited Platinum, SE, XLE | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Gate Lock, Rear
Part Number: 69350-0E100
$348.79 MSRP: $497.99
You Save: $149.20 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch; Tailgate Lock Actuator; Trunk Lock Actuator; Door Lock Actuator; Lock Actuator; Lock Assembly; Lock Assembly, Back Door, W/Courtesy Lamp Switch
- Position: Rear
- Replaces: 69350-0T010
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2010-2019 Toyota Highlander | Base, Hybrid LE, Hybrid Limited, Hybrid Limited Platinum, Hybrid XLE, LE, LE Plus, Limited, Limited Platinum, Plus, SE, Sport, XLE | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Gate Lock, Rear
Part Number: 69350-0E090
$348.79 MSRP: $497.99
You Save: $149.20 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch; Tailgate Lock Actuator; Trunk Lock Actuator; Door Lock Actuator; Lock Actuator; Lock Assembly; Lock Assembly, Back Door, W/Courtesy Lamp Switch
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2010-2019 Toyota Highlander | Base, Hybrid LE, Hybrid Limited, Hybrid Limited Platinum, Hybrid XLE, LE, LE Plus, Limited, Limited Platinum, Plus, SE, Sport, XLE | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Gate Lock, Rear
Part Number: 69350-28161
$213.30 MSRP: $304.55
You Save: $91.25 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch; Tailgate Lock Actuator; Trunk Lock Actuator; Door Lock Actuator; Lock Actuator; Lock Assembly; Lock
- Position: Rear
- Replaces: 69350-28160
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2013 Toyota Highlander | Base, Hybrid, Hybrid Limited, Limited, SE, Sport | 4 Cyl 2.7 L GAS, 6 Cyl 3.3 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Lock Assembly, Rear
Part Number: 69350-48020
$239.63 MSRP: $342.13
You Save: $102.50 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch, Rear; Door Lock Actuator; Door Lock; Lock; Lock Assembly, Back Door, W/Courtesy Lamp Switch
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2007 Toyota Highlander | Base, Hybrid, Hybrid Limited, Limited, Sport | 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L GAS, 6 Cyl 3.3 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.3 L GAS
View related parts
Toyota Highlander Gate Lock, Rear
Part Number: 69350-0E160
$186.74 MSRP: $266.61
You Save: $79.87 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch; Tailgate Lock Actuator; Trunk Lock Actuator; Door Lock Actuator; Lock Actuator; Lock; Lock Assembly, Back Door, W/Courtesy Lamp Switch
- Position: Rear
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2023 Toyota Highlander | Hybrid Bronze Edition, Hybrid LE, Hybrid XLE, L, LE, XLE, XSE | 4 Cyl 2.4 L GAS, 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Gate Lock, Rear
Part Number: 69350-0E151
$440.03 MSRP: $644.87
You Save: $204.84 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Lock Assembly, Back Door; Liftgate Latch, Rear; Lock Actuator; Lock Assembly, Back Door, W/Courtesy Lamp Switch
- Position: Rear
- Replaces: 69350-0E150
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2023 Toyota Highlander | Hybrid Bronze Edition, Hybrid LE, Hybrid Limited, Hybrid Platinum, Hybrid XLE, L, LE, Limited, Platinum, XLE, XSE | 4 Cyl 2.4 L GAS, 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.5 L GAS

Toyota Highlander Trunk Lid Latch

Choose genuine Trunk Lid Latch that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM Trunk Lid Latch for your Toyota Highlander? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Highlander parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

Toyota Highlander Trunk Lid Latch Parts and Q&A

Gate Lock, Rear
69350-28151
Q: How to remove the Trunk Lid Latch assembly on Toyota Highlander?
A:
The first step to remove the back door lock assembly requires the removal of the back window upper panel trim assembly. The left-hand side back door trim cover must be removed from non-power door vehicles whereas those with power doors need both the left-side back door service hole cover removed along with power back door rod disconnection. Vehicles that use a power back door need users to eliminate the left-hand side back door trim cover and the right-hand side back door trim cover in succession. The procedure begins by removing the back door lock cover if the hatch is glass until the assist strap hole cover and assist strap assembly can be unplugged. Next in the order move the back door trim panel assembly. Remove the three bolts and separate the back door lock assembly when working on vehicles without power back doors functionality. The assembly removal process for power back door vehicles requires connector detaching and clamp release as well as four bolt removal from the back door lock assembly.
Gate Lock, Rear
69350-28161
Q: How to install the Trunk Lid Latch assembly with and without a Power Back Door on Toyota Highlander?
A:
The back door lock assembly installation requires you to fasten 3 bolts at 13 Nm (133 kgf-cm, 10 ft-lbf) torque value and connect all connectors. The installation of the assembly with Power Back Door requires four same-torque bolts while connecting the connector before clamping it into place. The third step involves adding the back door trim panel assembly along with assist strap assembly and assist strap hole cover. The Glass Hatch Type requires a back door lock cover to be installed before both configurations (with and without Power Back Door) receive their left side back door trim cover. The service hole cover of the left Power Back Door needs the back door power rod connection followed by installation. The right side back door trim cover and the back window upper panel trim assembly should be installed as a final step.
