OEM Toyota Tundra Brake Master Cylinder

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Brake Master Cylinders found

View related parts
Toyota Tundra Master Cylinder
Part Number: 47201-0C071
$206.31 MSRP: $294.56
You Save: $88.25 (30%)
ADD TO CART
Product Specifications
- Other Name: Cylinder Sub-Assembly, Brake Stroke Simulator; Brake Master Cylinder; Brake Reservoir; Cylinder Sub-Assembly, Brake Master
- Replaces: 47201-0C070
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2007-2021 Toyota Tundra | 1794 Edition, Base, Limited, Nightshade, Platinum, SR, SR5, Trail, TRD Pro | 6 Cyl 4.0 L GAS, 8 Cyl 4.6 L GAS, 8 Cyl 4.7 L GAS, 8 Cyl 5.7 L FLEX, 8 Cyl 5.7 L GAS
View related parts
Toyota Tundra Master Cylinder
Part Number: 47207-0C010
$358.08 MSRP: $524.78
You Save: $166.70 (32%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Sub-Assembly, Brake Stroke Simulator; Brake Master Cylinder; Cylinder Sub-Assembly, Brake Master
- Replaces: 47207-34010
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004-2006 Toyota Tundra | Base, Limited, SR5 | 6 Cyl 3.4 L GAS, 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
Toyota Tundra Master Cylinder
Part Number: 47025-0C031
$1191.63 MSRP: $1746.34
You Save: $554.71 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Sub-Assembly; Brake Master Cylinder; Cylinder Sub-Assembly, Brake Master
- Manufacturer Note: W(VSC)
- Replaces: 47025-0C030
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2005-2006 Toyota Tundra | Base, Limited, SR5 | 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
Toyota Tundra Master Cylinder
Part Number: 47201-0C100
$179.51 MSRP: $256.30
You Save: $76.79 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Sub-Assembly, Brake Stroke Simulator; Brake Master Cylinder; Cylinder Sub-Assembly, Brake Master
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022-2024 Toyota Tundra | 1794 Edition, Capstone, Limited, Platinum, SR, SR5, TRD Pro | 6 Cyl 3.4 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.4 L GAS
View related parts
Toyota Tundra Master Cylinder
Part Number: 47055-0C020
$902.77 MSRP: $1323.01
You Save: $420.24 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Sub-Assembly, Brake Stroke Simulator; Brake Booster Assembly, W/Master Cylinder
- Manufacturer Note: *614
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022-2024 Toyota Tundra | 1794 Edition, Capstone, Limited, Platinum, TRD Pro | 6 Cyl 3.4 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.4 L GAS
View related parts
Toyota Tundra Master Cylinder
Part Number: 47055-0C010
$902.77 MSRP: $1323.01
You Save: $420.24 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cylinder Sub-Assembly, Brake Stroke Simulator; Brake Booster; Brake Booster Assembly, W/Master Cylinder
- Manufacturer Note: *614
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022-2024 Toyota Tundra | 1794 Edition, Capstone, Limited, Platinum, TRD Pro | 6 Cyl 3.4 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 3.4 L GAS
View related parts
Toyota Tundra Booster Assembly
Part Number: 47050-34010
Product Specifications
- Other Name: Cylinder Assembly, Brake; Power Brake Booster; Brake Booster Assembly, W/Master Cylinder; Brake Booster
- Manufacturer Note: W(VSC)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004 Toyota Tundra | Limited, SR5 | 6 Cyl 3.4 L GAS, 8 Cyl 4.7 L GAS
View related parts
Toyota Tundra Master Cylinder
Part Number: 47201-0C012
Product Specifications
- Other Name: Cylinder Sub-Assembly, Brake Stroke Simulator; Brake Master Cylinder; Brake Reservoir; Cylinder Sub-Assembly, Brake Master
- Manufacturer Note: W/O(VSC)
- Replaces: 47201-0C011, 47201-0C010
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2000-2006 Toyota Tundra | Base, Limited, SR5 | 6 Cyl 3.4 L GAS, 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
Toyota Tundra Brake Booster
Part Number: 47050-0C021
Product Specifications
- Other Name: Cylinder Assembly, Brake; Power Brake Booster; Booster Assembly; Brake Booster Assembly, W/Master Cylinder
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022-2023, 2005-2006 Toyota Tundra | 1794 Edition, Base, Capstone, Limited, Platinum, SR5, TRD Pro | 6 Cyl 3.4 L FULL HYBRID EV-GAS (FHEV), 6 Cyl 4.0 L GAS, 8 Cyl 4.7 L GAS
View related parts
Toyota Tundra Master Cylinder
Part Number: 47025-34020
Product Specifications
- Other Name: Cylinder Sub-Assembly, Brake Stroke Simulator; Brake Master Cylinder; Cylinder Sub-Assembly, Brake Master
- Manufacturer Note: W(VSC)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004 Toyota Tundra | Base, Limited, SR5 | 6 Cyl 3.4 L GAS, 8 Cyl 4.7 L GAS

Toyota Tundra Brake Master Cylinder

Choose genuine Brake Master Cylinder that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM Brake Master Cylinder for your Toyota Tundra? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Tundra parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

The Brake Master Cylinder in Toyota Tundra is among the most important braking system that determines the hydraulic pressure out of the foot pressure by the driver. This hydraulic pressure is transferred to the slave cylinders that activates the brakes and the required friction to bring the vehicle to a stop. It is normally constructed of cast iron or aluminum material members such as pistons, seals, and springs and contains the fluid reservoirs which can be either incorporated or detachable. Throughout the years, Tundra models have incorporated dual circuit master cylinders, thereby when one of the circuits offered for the supply of brakes is rendered ineffective, the other one can still supply the brakes. This design contributes to safety in the sense that the machine is not necessarily shut down in case of a hydraulic breakdown. Problems that are associated with the Brake Master Cylinder are fluid leakage and internal problems that affect the braking system. Another preventive measure, which must be taken regularly, is the inspection of the system for the presence of leaks and moisture.

Toyota Tundra Brake Master Cylinder Parts and Q&A

Master Cylinder
47201-0C071
Q: How to install the brake master cylinder on Toyota Tundra?
A:
Begin the brake master cylinder installation by placing a brake master cylinder seal onto the brake master unit then fasten the unit with 2 new nuts to achieve torque at 25 Nm (255 kgf-cm, 18 ft-lbf). Hold the front No. 1 brake tube (marked A) against the brake master cylinder and apply a torque of 20 Nm (199 kgf-cm, 14 ft-lbf) utilizing a union nut wrench which should be parallel to the torque wrench and possess a fulcrum length of 300 mm (11.8 in.) or apply a torque of 18 Nm (186 kgf-cm, 13 ft-lbf) when using the wrench. Follow the same torque specifications to attach the rear No. 1 brake tube (identified as B). You should then establish the connection for the brake fluid level warning switch before connecting the cable to the negative battery terminal although some systems need to complete an initial setup after reconnection. The mechanic must fill the brake fluid reservoir and perform air bleeding on the brake master cylinder and Brake Line and VSC actuator assembly while verifying the brake fluid level before inspecting for fluid leaks.
Master Cylinder
47207-0C010
Q: How to service and repair the Brake Master Cylinder on Toyota Tundra?
A:
Service and repair of the Brake Master Cylinder for Double Cab requires disconnecting the level warning switch connector while avoiding any adjustment of the brake booster push rod or modification of the diameter converting unit and brake combination. The next step involves fluid extraction with a syringe while paying attention to wash away brake fluid which touches painted surfaces immediately. Special Service Tool: 09023-00101 will help you remove the 5 Brake Lines from the master cylinder and 3-way by using a torque of 15 Nm (155 kgf-cm, 11 ft. lbs.). Change the front brake tube No.1 from the master cylinder and 3-way. The brake master cylinder removal starts with unscrewing the 2 nuts followed by the 3-way and brake master cylinder system and then tightening the parts to 13 Nm torque (130 kgf-cm, 9 ft. lbs.). The installation process should begin by performing the opposite removal sequences and adding brake fluid to the reservoir and bleeding the brake system. Before completion verify that all components are leak-free after you adjust the brake pedal positioning and check its height while testing the brake actuator with a handheld unit.
