How to replace the Park/Neutral Safety Switch Assy on Toyota Tacoma?

A proper park/neutral position switch assy replacement process starts with disconnecting both battery cable and park/neutral position switch connector. Start exchanging the park/neutral position switch assembly by driving out the lock washer stake then remove the nut, lock washer, grommet and finally remove both bolt and switch. The park/neutral position switch assy should be placed onto the manual valve lever shaft where you should initially adjust the bolt. Install the grommet followed by a new lock washer before adding the nut to the assembly while tightening it to 6.9 Nm (70 kgf-cm, 61 inch lbs.). The manual valve lever shaft needs to fit inside the groove then needs a clockwise rotation of 2 notches before aligning the neutral basic line with the switch groove while tightening the adjusting bolt to 13 Nm (130 kgf-cm, 9 ft. lbs. torque). Install the lock washer by bending at least two of its tabs and reattach the park/neutral position switch connector using cable wires to the negative battery terminal while tightening to 3.9 Nm (40 kgf-cm, 35 inch lbs.). Conclude by checking and readjusting both the park/neutral position switch assembly and shift lever position according to requirements.

How to Service and Repair the Neutral Safety Switch on Toyota Tacoma?

The process to maintain and fix the Transmission Position Switch/Sensor starts with front exhaust pipe and heat insulator removal. The service requires unfastening the oil cooler pipe first by removing the 3 oil cooler pipe clamps before disconnecting the oil cooler pipe. First disconnect the park/neutral position switch connector along with its lock washer then remove the switch nuts. To continue remove the bolt and take out the park/neutral position switch. The first step is to install the park/neutral position switch and bolt with proper torque settings of 5.4 Nm (55 kgf-cm, 48 inch lbs.) while installing a new lock plate together with its nut set to 3.9 Nm (40 kgf-cm, 35 inch lbs.) before bending the lock plate claws to keep the nut in place. Complete the adjustments of the park/neutral position switch before connecting the connector. Begin by fitting in the elbow together with the new O-ring before tightening it to 34 Nm (350 kgf-cm, 25 ft. lbs.). Proceed with attaching the oil cooler pipe using the same torque value and securing it using all 3 oil cooler pipe clamps. Put back the front exhaust pipe and the heat insulator as the last step.

OEM Toyota Tacoma Neutral Safety Switch

Transmission Neutral Safety Switch

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

12 Neutral Safety Switches found

View related parts
Toyota Tacoma Switch Assembly, Neutral Start
Part Number: 84540-60050
$130.77 MSRP: $185.11
You Save: $54.34 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral
- Replaces: 84540-04020
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2016-2021 Toyota Tacoma | Limited, SR, SR5, Trail, TRD Off-Road, TRD Pro, TRD Sport | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS
View related parts
Toyota Tacoma Neutral Safety Switch
Part Number: 84520-42010
$52.33 MSRP: $72.84
You Save: $20.51 (29%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Clutch; Clutch Switch; Switch Assembly, Cruise Control Cancel; Switch Assembly, Clutch Start
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2005-2022 Toyota Tacoma | Base, Limited, Pre Runner, SR, SR5, Trail, TRD Off-Road, TRD Pro, TRD Sport, X-Runner | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS, 6 Cyl 4.0 L GAS
View related parts
Toyota Tacoma Switch Assembly, Neutral Start
Part Number: 84540-51010
$162.61 MSRP: $230.19
You Save: $67.58 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2004 Toyota Tacoma | Base, Pre Runner, S-Runner | 4 Cyl 2.4 L GAS, 4 Cyl 2.7 L GAS, 6 Cyl 3.4 L GAS
View related parts
Toyota Tacoma Range Sensor
Part Number: 84540-35050
$143.81 MSRP: $203.58
You Save: $59.77 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral; Switch Assembly, Neutral Start
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2005-2015 Toyota Tacoma | Base, Pre Runner, TRD Pro, X-Runner | 4 Cyl 2.7 L GAS, 6 Cyl 4.0 L GAS
View related parts
Toyota Tacoma Neutral Safety Switch
Part Number: 84540-30300
$130.77 MSRP: $185.11
You Save: $54.34 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral; Switch Assembly, Neutral Start
- Manufacturer Note: MATSUSHITA
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1995-2003 Toyota Tacoma | Base, DLX, SR5 | 4 Cyl 2.4 L GAS
View related parts
Toyota Tacoma Neutral Safety Switch
Part Number: 84540-30290
$130.77 MSRP: $185.11
You Save: $54.34 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral; Switch Assembly, Neutral Start
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1995-2003 Toyota Tacoma | Base, DLX, SR5 | 4 Cyl 2.4 L GAS
View related parts
Toyota Tacoma Switch Assembly, Neutral Start
Part Number: 84540-30270
$144.51 MSRP: $204.57
You Save: $60.06 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1995-2000 Toyota Tacoma | Base, DLX, Limited, Pre Runner, SR5 | 4 Cyl 2.4 L GAS, 4 Cyl 2.7 L GAS, 6 Cyl 3.4 L GAS
View related parts
Toyota Tacoma Switch Assembly, Neutral Start
Part Number: 84540-04010
$130.77 MSRP: $185.11
You Save: $54.34 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral
- Manufacturer Note: (L)
- Replaces: 84540-71010
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2005-2015 Toyota Tacoma | Base, Pre Runner, TRD Pro, X-Runner | 4 Cyl 2.7 L GAS, 6 Cyl 4.0 L GAS
View related parts
Toyota Tacoma Neutral Safety Switch
Part Number: 84520-24010
$65.28 MSRP: $91.63
You Save: $26.35 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Clutch; Clutch Starter Safety Switch; Starter Safety Switch; Safety Switch; Clutch Switch; Switch; Switch Assembly, Clutch Start
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1995-2004 Toyota Tacoma | Base, DLX, Limited, Pre Runner, SR5, S-Runner | 4 Cyl 2.4 L GAS, 4 Cyl 2.7 L GAS, 6 Cyl 3.4 L GAS
View related parts
Toyota Tacoma Range Sensor
Part Number: 84545-71010
$64.93 MSRP: $91.13
You Save: $26.20 (29%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch, Neutral Position
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2022 Toyota Tacoma | Limited, SR, SR5, Trail, TRD Off-Road, TRD Pro, TRD Sport | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS
View related parts
Toyota Tacoma Range Sensor
Part Number: 84540-35061
$130.77 MSRP: $185.11
You Save: $54.34 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral; Switch Assembly, Neutral Start
- Manufacturer Note: (J)
- Replaces: 84540-35060
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022 Toyota Tacoma | Limited, SR, SR5, TRD Off-Road, TRD Pro, TRD Sport | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS
View related parts
Toyota Tacoma Range Sensor
Part Number: 84540-04021
$130.77 MSRP: $185.11
You Save: $54.34 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Switch Assembly, Neutral; Switch Assembly, Neutral Start
- Manufacturer Note: (L)
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2022 Toyota Tacoma | Limited, SR, SR5, TRD Off-Road, TRD Pro, TRD Sport | 4 Cyl 2.7 L GAS, 6 Cyl 3.5 L GAS

Toyota Tacoma Neutral Safety Switch

Choose genuine Neutral Safety Switch that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM Neutral Safety Switch for your Toyota Tacoma? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Tacoma parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

Toyota Tacoma Neutral Safety Switch Parts and Q&A

Neutral Safety Switch
84520-42010
Q: How to replace the Park/Neutral Safety Switch Assy on Toyota Tacoma?
A:
A proper park/neutral position switch assy replacement process starts with disconnecting both battery cable and park/neutral position switch connector. Start exchanging the park/neutral position switch assembly by driving out the lock washer stake then remove the nut, lock washer, grommet and finally remove both bolt and switch. The park/neutral position switch assy should be placed onto the manual valve lever shaft where you should initially adjust the bolt. Install the grommet followed by a new lock washer before adding the nut to the assembly while tightening it to 6.9 Nm (70 kgf-cm, 61 inch lbs.). The manual valve lever shaft needs to fit inside the groove then needs a clockwise rotation of 2 notches before aligning the neutral basic line with the switch groove while tightening the adjusting bolt to 13 Nm (130 kgf-cm, 9 ft. lbs. torque). Install the lock washer by bending at least two of its tabs and reattach the park/neutral position switch connector using cable wires to the negative battery terminal while tightening to 3.9 Nm (40 kgf-cm, 35 inch lbs.). Conclude by checking and readjusting both the park/neutral position switch assembly and shift lever position according to requirements.
Neutral Safety Switch
84540-30300
Q: How to Service and Repair the Neutral Safety Switch on Toyota Tacoma?
A:
The process to maintain and fix the Transmission Position Switch/Sensor starts with front Exhaust Pipe and heat insulator removal. The service requires unfastening the oil cooler pipe first by removing the 3 oil cooler pipe clamps before disconnecting the oil cooler pipe. First disconnect the park/neutral position switch connector along with its lock washer then remove the switch nuts. To continue remove the bolt and take out the park/neutral position switch. The first step is to install the park/neutral position switch and bolt with proper torque settings of 5.4 Nm (55 kgf-cm, 48 inch lbs.) while installing a new lock plate together with its nut set to 3.9 Nm (40 kgf-cm, 35 inch lbs.) before bending the lock plate claws to keep the nut in place. Complete the adjustments of the park/neutral position switch before connecting the connector. Begin by fitting in the elbow together with the new O-ring before tightening it to 34 Nm (350 kgf-cm, 25 ft. lbs.). Proceed with attaching the oil cooler pipe using the same torque value and securing it using all 3 oil cooler pipe clamps. Put back the front exhaust pipe and the heat insulator as the last step.
