How to install the exhaust pipe on Toyota Highlander?

One should start exhaust pipe installation by adding the Bank 2 Sensor 2 heated oxygen sensor for the 2GR-FE engine. First install a new gasket onto the front exhaust pipe assembly before tightening it with two new nuts that need torquing to 56 Nm (571 kgf-cm, 41 ft-lbf). Afterwards attach the heated oxygen sensor for Bank 2 Sensor 2. The installation process for Bank 1 Sensor 2 heated oxygen sensor should follow next. Install the front No. 3 exhaust pipe sub-assembly by setting two new gaskets followed by tightening two new nuts and two bolts to 56 Nm (571 kgf-cm, 41 ft-lbf) while also adding three clamps before connecting the heated oxygen sensor for Bank 1 Sensor 2 then screwing the front exhaust pipe assembly bolt to 21 Nm (214 kgf-cm, 15 ft-lbf). Measure the compression spring free length in the center exhaust pipe assembly using vernier calipers until it shows minimum requirements for replacement. Install and flatten a fresh gasket against the front No. 3 exhaust pipe sub-assembly by using a plastic-faced hammer and wooden block until it reaches the correct installation depth. Discard the used gasket. Please secure the center exhaust pipe assembly by mounting it with two compression springs alongside two bolts following a torque of 48 Nm (489 kgf-cm, 35 ft-lbf). Use two bolts to mount the exhaust pipe damper while torquing them to 19 Nm (194 kgf-cm, 14 ft-lbf). The tail exhaust pipe assembly installation requires free compression spring length measurement for replacement purposes followed by new gasket positioning until it reaches the center exhaust pipe assembly while avoiding reverse installation and reuse of removed gaskets. The exhaust pipe support must be attached to the assembly by using two compression springs and two bolts which should receive a torque setting of 48 Nm (489 kgf-cm, 35 ft-lbf). Exhaust gas leaks should be inspected and the replacement of damaged parts with new components must be performed before installing the No. 2 engine under cover, No. 1 engine under cover, and engine under cover assembly.

How to remove the exhaust pipe on Toyota Highlander?

A 2GR-FE engine requires users to begin their exhaust pipe removal process by disassembling the engine under cover assembly then removing the No. 1 and No. 2 engine under covers. The sequence to detach the tail exhaust pipe assembly involves two bolt removal and two compression spring removal along with the disconnect of the exhaust pipe support and eventually extraction of the gasket from the center exhaust pipe assembly. After removing the exhaust pipe damper you must take out its 2 bolts. The center exhaust pipe assembly requires removal of its 2 bolts along with 2 compression springs followed by disconnecting the 3 exhaust pipe supports to extract the gasket from the No. 3 exhaust pipe sub-assembly. Start by removing the 3 clamps on the front No. 3 exhaust pipe sub-assembly then disconnect the heated oxygen sensor (for bank 1 sensor 2) connector after which you should remove the 2 bolts, 2 nuts and finally the sub-assembly with 2 gaskets. The maintenance continues by disconnecting the heated oxygen sensor connector (for bank 2 sensor 2), then loosening the bolt before removing the 2 nuts together with the front exhaust pipe assembly and extracting the gasket from the front exhaust pipe assembly.

OEM Toyota Highlander Exhaust Pipe

Exhaust Tail Pipe

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

68 Exhaust Pipes found

View related parts
Toyota Highlander Front Pipe
Part Number: 17410-0V321
$1040.90 MSRP: $1397.19
You Save: $356.29 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Pipe; Pipe Assembly, Exhaust, Front
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2017-2019 Toyota Highlander | LE | 4 Cyl 2.7 L GAS
View related parts
Toyota Highlander Muffler & Pipe, Center
Part Number: 17420-20420
$1714.18 MSRP: $2300.93
You Save: $586.75 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Intermediate Pipe, Rear; Exhaust Muffler; Exhaust Pipe; Tail Pipe; Muffler; Pipe Assembly, Exhaust, Center
- Position: Center
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2008-2010 Toyota Highlander | Hybrid, Hybrid Limited | 6 Cyl 3.3 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Highlander Front Pipe
Part Number: 17410-F0290
$1148.15 MSRP: $1541.16
You Save: $393.01 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Intermediate Pipe, Front; Exhaust Pipe; Pipe Assembly, Exhaust, Front
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2023 Toyota Highlander | Hybrid Bronze Edition, Hybrid LE, Hybrid Limited, Hybrid Platinum, Hybrid XLE | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Highlander Front Pipe
Part Number: 17410-0V040
$1236.68 MSRP: $1659.99
You Save: $423.31 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Catalytic Converter; Exhaust Pipe; Pipe Assembly, Exhaust, Front
- Position: Front
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2011-2013 Toyota Highlander | Base, Plus, SE | 4 Cyl 2.7 L GAS
View related parts
Toyota Highlander Intermediate Pipe, Center
Part Number: 17420-28110
$419.71 MSRP: $563.38
You Save: $143.67 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Pipe; Center Pipe; Pipe Assembly, Exhaust, Center
- Position: Center
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2001-2003 Toyota Highlander | Base | 4 Cyl 2.4 L GAS
View related parts
Toyota Highlander Muffler & Pipe Assembly
Part Number: 17430-F0300
$578.95 MSRP: $777.12
You Save: $198.17 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust Tail; Exhaust Muffler; Exhaust Pipe; Tail Pipe; Muffler & Pipe; Pipe Assembly, Exhaust, Tail; Muffler
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2023 Toyota Highlander | Hybrid Bronze Edition, Hybrid LE, Hybrid Limited, Hybrid Platinum, Hybrid XLE | 4 Cyl 2.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Highlander Rear Pipe
Part Number: 17420-0P372
$1542.11 MSRP: $2069.97
You Save: $527.86 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Pipe; Tail Pipe; Muffler; Muffler & Pipe
- Replaces: 17420-0P371
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2014-2016 Toyota Highlander | Hybrid Limited | 6 Cyl 3.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Highlander Muffler & Pipe, Center
Part Number: 17420-36040
$1643.92 MSRP: $2206.62
You Save: $562.70 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Pipe; Tail Pipe; Muffler; Pipe Assembly, Exhaust, Center
- Position: Center
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2009-2010 Toyota Highlander | Base | 4 Cyl 2.7 L GAS
View related parts
Toyota Highlander Center Pipe, Rear
Part Number: 17420-0P531
$905.72 MSRP: $1215.74
You Save: $310.02 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Intermediate Pipe, Rear
- Position: Rear
- Replaces: 17420-0P530
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020 Toyota Highlander | L, LE, Limited, Platinum, XLE | 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Rear Muffler
Part Number: 17430-0V301
$670.66 MSRP: $900.22
You Save: $229.56 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust Tail; Muffler; Pipe Assembly, Exhaust, Tail
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2017-2019 Toyota Highlander | LE | 4 Cyl 2.7 L GAS
View related parts
Toyota Highlander Intermediate Pipe, Center
Part Number: 17420-28460
$1213.98 MSRP: $1629.52
You Save: $415.54 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Muffler Assembly; Direct-Fit Exhaust; Exhaust System Kit; Exhaust Pipe; Center Pipe; Pipe Assembly, Exhaust, Center
- Position: Center
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2004-2007 Toyota Highlander | Base | 4 Cyl 2.4 L GAS
View related parts
Toyota Highlander Muffler & Pipe
Part Number: 17420-31403
$1684.10 MSRP: $2260.55
You Save: $576.45 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Muffler; Exhaust Pipe; Tail Pipe; Muffler
- Replaces: 17420-31401, 17420-31400, 17420-31402
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2011-2013 Toyota Highlander | Hybrid, Hybrid Limited | 6 Cyl 3.5 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Highlander Muffler & Pipe
Part Number: 17430-F0530
$547.06 MSRP: $734.32
You Save: $187.26 (26%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust Tail; Pipe Assembly, Exhaust, Tail
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023 Toyota Highlander | XSE | 4 Cyl 2.4 L GAS
View related parts
Toyota Highlander Center Pipe
Part Number: 17420-0P581
$974.73 MSRP: $1308.36
You Save: $333.63 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Intermediate Pipe, Rear; Pipe Assembly, Exhaust, Center
- Position: Center
- Replaces: 17420-0P580
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2021-2022 Toyota Highlander | L, LE, Limited, Platinum, XLE, XSE | 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Rear Pipe, Center
Part Number: 17420-0P482
$904.92 MSRP: $1214.68
You Save: $309.76 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Catalytic Converter, Rear; Exhaust Pipe; Tail Pipe; Muffler; Muffler & Pipe; Pipe Assembly, Exhaust, Center
- Position: Center
- Replaces: 17420-0P481
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2017-2019 Toyota Highlander | LE, LE Plus, Limited, Limited Platinum, SE, XLE | 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Muffler & Pipe, Center
Part Number: 17420-0V050
$1369.37 MSRP: $1838.09
You Save: $468.72 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Pipe; Tail Pipe; Muffler; Pipe Assembly, Exhaust, Center
- Position: Center
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2011-2013 Toyota Highlander | Base, Plus, SE | 4 Cyl 2.7 L GAS
View related parts
Toyota Highlander Muffler & Pipe Assembly
Part Number: 17430-F0290
$565.90 MSRP: $759.61
You Save: $193.71 (26%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust Tail; Pipe Assembly, Exhaust, Tail
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2023 Toyota Highlander | L, LE, Limited, Platinum, XLE, XSE | 4 Cyl 2.4 L GAS
View related parts
Toyota Highlander Muffler & Pipe Assembly
Part Number: 17430-0P631
$575.09 MSRP: $771.95
You Save: $196.86 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust Tail; Exhaust Muffler; Muffler & Pipe; Pipe Assembly, Exhaust, Tail
- Replaces: 17430-0P630
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2021-2022 Toyota Highlander | XSE | 6 Cyl 3.5 L GAS
View related parts
Toyota Highlander Rear Muffler
Part Number: 17430-0V300
$593.93 MSRP: $797.24
You Save: $203.31 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust Tail; Muffler; Pipe Assembly, Exhaust, Tail
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2014-2016 Toyota Highlander | LE | 4 Cyl 2.7 L GAS
View related parts
Toyota Highlander Intermediate Pipe, Center
Part Number: 17420-0V301
$985.28 MSRP: $1322.53
You Save: $337.25 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly, Exhaust; Exhaust Intermediate Pipe; Exhaust Pipe; Center Pipe; Muffler; Pipe Assembly, Exhaust, Center
- Position: Center
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2017-2019 Toyota Highlander | LE | 4 Cyl 2.7 L GAS

| Page 1 of 4 |Next >

1-20 of 68 Results

Toyota Highlander Exhaust Pipe

Choose genuine Exhaust Pipe that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM Exhaust Pipe for your Toyota Highlander? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Highlander parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

The Toyota Highlander Exhaust Pipe is among these parts because it shows how much this vehicle is dependable and efficient. The right pipe also has a great function of discharging detrimental fumes like carbon monoxide from the engine so as to provide a healthy environment in the car. close coupled with muffler and catalytic converter, the Toyota Highlander Exhaust Pipe helps to effectively discharge emitted fumes beneficial for the improvement of the efficiency and safety of the vehicle. Suitable for Highlander manufactured in different years, 5- and 7-Seater with both Front-Wheel Drive and All-Wheel Drive Gas Exports are designed depending on the car's model. Arguably, the Highlander may possess distinct exhaust outlets with the standard central or independent pipes for performance trims to add to Toyota's versatility characteristics. Being exposed, the exhaust pipe can easily get damaged and this will compromise its performance and moreover give room to dangerous leaks. Nonetheless, the construction of the Toyota Highlander Exhaust Pipe is strong and long-lasting; thus making it popular in the automobile market. Moreover, the innovative technology further enriches the exhaust pipe with the improved components of such hybrid models as Toyota Hybrid Synergy Drive. All in all, the Toyota Highlander Exhaust Pipe represents a must-have part in order to preserve the car's performance, safety, and eco-friendliness - thus cementing the Highlander's position as a car worth driving.

Toyota Highlander Exhaust Pipe Parts and Q&A

Muffler & Pipe, Center
17420-0P150
Q: How to install the exhaust pipe on Toyota Highlander?
A:
One should start exhaust pipe installation by adding the Bank 2 Sensor 2 heated Oxygen Sensor for the 2GR-FE engine. First install a new gasket onto the front exhaust pipe assembly before tightening it with two new nuts that need torquing to 56 Nm (571 kgf-cm, 41 ft-lbf). Afterwards attach the heated oxygen sensor for Bank 2 Sensor 2. The installation process for Bank 1 Sensor 2 heated oxygen sensor should follow next. Install the front No. 3 exhaust pipe sub-assembly by setting two new gaskets followed by tightening two new nuts and two bolts to 56 Nm (571 kgf-cm, 41 ft-lbf) while also adding three clamps before connecting the heated oxygen sensor for Bank 1 Sensor 2 then screwing the front exhaust pipe assembly bolt to 21 Nm (214 kgf-cm, 15 ft-lbf). Measure the compression spring free length in the center exhaust pipe assembly using vernier calipers until it shows minimum requirements for replacement. Install and flatten a fresh gasket against the front No. 3 exhaust pipe sub-assembly by using a plastic-faced hammer and wooden block until it reaches the correct installation depth. Discard the used gasket. Please secure the center exhaust pipe assembly by mounting it with two compression springs alongside two bolts following a torque of 48 Nm (489 kgf-cm, 35 ft-lbf). Use two bolts to mount the exhaust pipe damper while torquing them to 19 Nm (194 kgf-cm, 14 ft-lbf). The tail exhaust pipe assembly installation requires free compression spring length measurement for replacement purposes followed by new gasket positioning until it reaches the center exhaust pipe assembly while avoiding reverse installation and reuse of removed gaskets. The exhaust pipe support must be attached to the assembly by using two compression springs and two bolts which should receive a torque setting of 48 Nm (489 kgf-cm, 35 ft-lbf). Exhaust gas leaks should be inspected and the replacement of damaged parts with new components must be performed before installing the No. 2 engine under cover, No. 1 engine under cover, and engine under cover assembly.
Tail Pipe
17430-31580
Q: How to remove the exhaust pipe on Toyota Highlander?
A:
A 2GR-FE engine requires users to begin their exhaust pipe removal process by disassembling the engine under cover assembly then removing the No. 1 and No. 2 engine under covers. The sequence to detach the tail exhaust pipe assembly involves two bolt removal and two compression spring removal along with the disconnect of the exhaust pipe support and eventually extraction of the gasket from the center exhaust pipe assembly. After removing the exhaust pipe damper you must take out its 2 bolts. The center exhaust pipe assembly requires removal of its 2 bolts along with 2 compression springs followed by disconnecting the 3 exhaust pipe supports to extract the gasket from the No. 3 exhaust pipe sub-assembly. Start by removing the 3 clamps on the front No. 3 exhaust pipe sub-assembly then disconnect the heated Oxygen Sensor (for bank 1 sensor 2) connector after which you should remove the 2 bolts, 2 nuts and finally the sub-assembly with 2 gaskets. The maintenance continues by disconnecting the heated oxygen sensor connector (for bank 2 sensor 2), then loosening the bolt before removing the 2 nuts together with the front exhaust pipe assembly and extracting the gasket from the front exhaust pipe assembly.
