OEM Toyota Corolla Throttle Body
Fuel Injection Throttle Body- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
28 Throttle Bodies found
Toyota Corolla Throttle Body
Part Number: 22210-0D110$396.44 MSRP: $581.00You Save: $184.56 (32%)Ships in 1-3 Business Days
Toyota Corolla Throttle Body
Part Number: 22030-0D031$375.33 MSRP: $550.06You Save: $174.73 (32%)Ships in 1-2 Business Days
| Page 1 of 2 |Next >
1-20 of 28 Results
Toyota Corolla Throttle Body
Choose genuine Throttle Body that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM Throttle Body for your Toyota Corolla? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Corolla parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.
The Throttle Body is a component of Toyota Corolla automobiles that manages the quantity and speed of the air that is drawn into the engine including based on the movement of the accelerator pedal of the automobile. Located between the air filter box and the intake manifold, the throttle body has a butterfly valve that helps control the amount of air being taken into the engine. In fuel injected engines the throttle body is very important in regulating the right ration of air and fuel supplied to the car engine by injecting more fuel when the throttle plate is opened. Some Toyota Corolla models may use Electronic Throttle Control (ETC), that removes all mechanical problems and interconnects the throttle with systems. There is the possibility of cleaning them in order to rectify some problems for instance rough idle but at times they have to be replaced. In general, changes in throttle bodies and the use of advanced technologies like fuel injection systems are evident changes that portray the general improvements of control and efficiency of Toyota Corolla vehicles.
Toyota Corolla Throttle Body Parts and Q&A
- Q: How to remove the throttle body assembly on Toyota Corolla?A:Before starting the throttle body assembly removal on the 2ZR-FE engine you have to drain the engine coolant. Afterward remove the No. 2 cylinder head cover. Begin the air cleaner cap sub-assembly removal by disconnecting both the mass air flow meter connector and two wire harness clamps followed by unhinging the ventilation hose and loosening its clamp. The removal of the air cleaner cap sub-assembly with connected hose occurs after releasing both clamp holders. Disconnection of throttle body connector along with two water by-pass hoses allows you to remove the two bolts and two nuts before removing the throttle body assembly. Complete the removal process by taking out the gasket from the Intake Manifold.
- Q: How to install the throttle body assembly on Toyota Corolla?A:The 2ZR-FE engine control throttle body assembly installation requires first placing a new gasket onto the Intake Manifold followed by using 2 bolts and 2 nuts to secure the throttle body assembly and tightening the bolts to 10 Nm (102 kgf-cm, 7 ft-lbf). Secondly connect both water by-pass hoses and throttle body connector. The installation of the air cleaner cap sub-assembly requires attaching it with the hose using 2 clamps while tightening each clamp to a torque setting of 2.0 Nm (20 kgf-cm, 18 in-lbf). Also connect the ventilation hose along with the 2 wire harness clamps and mass air flow meter connector. Engine coolant should be added to the system after which you must check for any leaks. First install the No. 2 cylinder head cover before beginning initialization by waiting 60 seconds with the negative (-) battery terminal disconnected from the cable before reconnecting it. Turn the ignition to ON while keeping the accelerator pedal static. Reinitialize the process if you need to operate the accelerator. The technician must first connect the Techstream system to the DLC3 before proceeding with DTCs deletion. Verify that the MIL remains off and engine speed falls within specifications after the engine warms up with air conditioning off while also maintaining all accessories in off mode and the shift lever in N or P. Check the throttle position sensor output in the Powertrain/Engine through ECT/Data List. Confirm that the value reaches at least 60% while holding the accelerator pedal fully down. The last step should include testing the vehicle on the road to make sure everything operates correctly.
