How to install the intake manifold on Toyota Corolla?

Installing the 2ZR-FE intake manifold begins with torquing the "TORX" socket E6 through 2 stud bolts until they reach 5.0 Nm (51 kgf-cm, 44 in-lbf). Install the bracket first using a bolt which should be tightened to 10 Nm (102 kgf-cm, 8 ft-lbf) while placing a new gasket inside the intake manifold. After placing the intake manifold alongside the intake manifold stay apply 4 bolts together with 2 nuts until the torque reaches 28 Nm (286 kgf-cm, 21 ft-lbf). The 3 hoses should be connected after users torque the wire harness bracket to 10 Nm (102 kgf-cm, 8 ft-lbf) using a bolt. The throttle body assembly requires installation before moving to the air cleaner cap sub-assembly and then the No. 2 cylinder head cover. The fluid capacity should be checked before adding engine coolant while conducting a systematic leak inspection.

How to remove the intake manifold on Toyota Corolla?

First step for removing an intake manifold from a 2ZR-FE engine is to drain all engine coolant. Begin by taking out the No. 2 cylinder head cover then execute the removal of air cleaner cap sub-assembly along with the throttle body assembly. You should begin the intake manifold removal by detaching the wire harness bracket followed by bolt removal then disconnecting three hoses before taking out four bolts and two nuts and removing the intake manifold stay and finally extracting the intake manifold. You need to remove both the intake manifold gasket followed by the bolt accompanied by the bracket. remove the two stud bolts from the intake manifold by using a "TORX" socket E6.

OEM Toyota Corolla Intake Manifold

Engine Intake Manifold

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

14 Intake Manifolds found

View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-0T080
$272.60 MSRP: $389.21
You Save: $116.61 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Engine Intake Manifold; Manifold, Intake
- Manufacturer Note: (L)
- Replaces: 17120-37031
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2014-2022 Toyota Corolla | 50th Anniversary Special Edition, L, LE, LE Eco, Le Eco Plus, S, SE, Special Edition, XLE, XSE | 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-0T011
$299.16 MSRP: $427.13
You Save: $127.97 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Engine Intake Manifold; Manifold, Intake
- Replaces: 17120-0T010, 17120-37020, 17120-37021
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2009-2010 Toyota Corolla | Base, LE, S, XLE | 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-0H081
$328.63 MSRP: $469.22
You Save: $140.59 (30%)
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Engine Intake Manifold; Manifold, Intake
- Manufacturer Note: (L)
- Replaces: 17120-28170, 17120-0H080
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2009-2010 Toyota Corolla | XRS | 4 Cyl 2.4 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-F2010
$269.57 MSRP: $384.89
You Save: $115.32 (30%)
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Engine Intake Manifold; Manifold, Intake
- Manufacturer Note: *702
- Replaces: 17120-24010
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2019-2024 Toyota Corolla | LE, Nightshade, SE, SE Apex, SE Nightshade, XSE, XSE Apex | 4 Cyl 2.0 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-37110
$233.45 MSRP: $333.32
You Save: $99.87 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Engine Intake Manifold; Manifold, Intake
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2020-2023 Toyota Corolla | Hybrid LE, Hybrid SE, Hybrid XLE | 4 Cyl 1.8 L FULL HYBRID EV-GAS (FHEV)
View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-0T012
$221.57 MSRP: $316.35
You Save: $94.78 (30%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Engine Intake Manifold; Manifold, Intake
- Replaces: 17120-37022
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2011-2019 Toyota Corolla | 50th Anniversary Special Edition, Base, L, LE, LE Eco, Le Eco Plus, S, SE, Special Edition, XLE, XSE | 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-0D080
$375.45 MSRP: $550.22
You Save: $174.77 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Manifold, Intake
- Manufacturer Note: (L)
- Replaces: 17120-22070
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2005-2008 Toyota Corolla | CE, LE, S | 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17111-88601
$349.31 MSRP: $498.74
You Save: $149.43 (30%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Manifold, Intake
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2005-2006 Toyota Corolla | XRS | 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17120-0D040
$366.03 MSRP: $536.42
You Save: $170.39 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Manifold Assembly, Intake; Manifold, Intake
- Manufacturer Note: (L)
- Replaces: 17120-22030
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 2003-2004 Toyota Corolla | CE, LE, S | 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17101-22010
Product Specifications
- Other Name: Manifold Sub-Assembly, Intake; Manifold, Intake
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1998-2002 Toyota Corolla | CE, LE, S, VE | 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17101-16260
Product Specifications
- Other Name: Manifold Sub-Assembly, Intake; Manifold, Intake
- Replaces: 17101-16240
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1995-1997 Toyota Corolla | Base, CE, DX, LE | 4 Cyl 1.6 L GAS, 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17101-16190
Product Specifications
- Other Name: Manifold Sub-Assembly, Intake; Manifold, Intake
- Replaces: 17101-16200
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1993-1995 Toyota Corolla | Base, DX, LE | 4 Cyl 1.6 L GAS, 4 Cyl 1.8 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17101-16170
Product Specifications
- Other Name: Manifold Sub-Assembly, Intake; Manifold, Intake
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1991-1992 Toyota Corolla | Base, DLX, DLX All Trac, GTS, LE, SR5 | 4 Cyl 1.6 L GAS
View related parts
Toyota Corolla Intake Manifold
Part Number: 17101-16140
Product Specifications
- Other Name: Manifold Sub-Assembly, Intake; Manifold, Intake
- Warranty: This genuine part is guaranteed by Toyota's factory warranty.
Fits the following Vehicles:
- 1991-1992 Toyota Corolla | Base, DLX, DLX All Trac, GTS, LE, SR5 | 4 Cyl 1.6 L GAS

Toyota Corolla Intake Manifold

Choose genuine Intake Manifold that pass strict quality control tests. You can trust the top quality and lasting durability. Shopping for OEM Intake Manifold for your Toyota Corolla? Our website is your one-stop destination. We stock an extensive selection of genuine Toyota Corolla parts. The price is affordable so you can save more. It only takes minutes to browse and find the exact fit. Easily add to cart and check out fast. Our hassle-free return policy will keep you stress-free. We process orders quickly for swift delivery. Your parts will arrive faster, so you can get back on the road sooner.

Toyota Corolla Intake Manifold Parts and Q&A

Intake Manifold
17120-0T011
Q: How to install the intake manifold on Toyota Corolla?
A:
Installing the 2ZR-FE intake manifold begins with torquing the "TORX" socket E6 through 2 stud bolts until they reach 5.0 Nm (51 kgf-cm, 44 in-lbf). Install the bracket first using a bolt which should be tightened to 10 Nm (102 kgf-cm, 8 ft-lbf) while placing a new gasket inside the intake manifold. After placing the intake manifold alongside the intake manifold stay apply 4 bolts together with 2 nuts until the torque reaches 28 Nm (286 kgf-cm, 21 ft-lbf). The 3 hoses should be connected after users torque the wire harness bracket to 10 Nm (102 kgf-cm, 8 ft-lbf) using a bolt. The Throttle Body assembly requires installation before moving to the air cleaner cap sub-assembly and then the No. 2 cylinder head cover. The fluid capacity should be checked before adding engine coolant while conducting a systematic leak inspection.
Intake Manifold
17120-0H081
Q: How to remove the intake manifold on Toyota Corolla?
A:
First step for removing an intake manifold from a 2ZR-FE engine is to drain all engine coolant. Begin by taking out the No. 2 cylinder head cover then execute the removal of air cleaner cap sub-assembly along with the Throttle Body assembly. You should begin the intake manifold removal by detaching the wire harness bracket followed by bolt removal then disconnecting three hoses before taking out four bolts and two nuts and removing the intake manifold stay and finally extracting the intake manifold. You need to remove both the intake manifold gasket followed by the bolt accompanied by the bracket. remove the two stud bolts from the intake manifold by using a "TORX" socket E6.
