Toyota 87165-45030
Control Module

The blower motor controller needs secure attachment with its two screws followed by connector connection. Afterward install the roof side inner garnish assembly RH, deck trim side panel assembly RH, front deck side trim cover RH, No. 1 luggage compartment trim hook, rope hook assembly (for RH side), rear combination light service cover RH, side trim cover RH (for Manual Air Conditioning System), and rear room temperature sensor (for Automatic Air Conditioning System). Begin by fixing the rear seat side garnish cap and deck side trim cover RH and deck side trim RH as well as the rear floor finish plate and rear No. 2 seat assembly and connect the rear seat lap type belt assembly LH and RH. The installation process includes adding rear No. 2 seat inner belt assembly, rear mat, deck floor board assembly, deck side trim box LH, rear seat side cover LH, deck side trim box RH, jack carrier assembly, jack assembly, jack carrier cushion, jack carrier support, rear seat side cover RH, tonneau cover assembly (w/ Tonneau Cover), No. 2 deck board sub-assembly, No. 3 deck board sub-assembly, deck board assembly, rear door opening trim Weather Strip RH, and rear door scuff plate RH.

Secure the blower motor controller through two screws before you establish the connector. The next order of installation includes the roof side inner garnish assembly RH followed by the deck trim side panel assembly RH, then the front deck side trim cover RH. Mount the No. 1 luggage compartment trim hook before you install the rope hook assembly for the RH side along with the rear combination light service cover RH. The side trim cover RH needs installation with the screws during manual air conditioning system installation yet automatic air conditioning systems require installation of the rear room temperature sensor. The next sequence of installation consists of the deck side trim RH followed by its cover RH and then the rear seat side garnish cap and finally the rear floor finish plate. The vehicle gets its rear No. 2 seat assembly which requires both rear seat lap type belt assemblies LH and RH to be connected along with the rear No. 2 seat inner belt assembly installation. The installation requires the rear mat alongside the deck floor board assembly and deck side trim box LH and rear seat side cover LH. The installation sequence requires putting on the deck side trim box RH followed by the jack carrier assembly and the jack assembly and finally the jack carrier cushion. Install the jack carrier support along with the rear seat side cover RH, the tonneau cover assembly with tonneau cover, the No. 2 deck board sub-assembly, the No. 3 deck board sub-assembly and the deck board assembly. Users should install the rear door opening trim Weather Strip RH before placing the rear door scuff plate RH.

Remove the tonneau cover assembly (with tonneau cover).

Remove the rear door opening trim weatherstrip RH.
